About the Nano 30CS
Nano 30 CS is a compact electric push-around platform designed for elevated access tasks in confined and restricted indoor environments up to 4.95 m. Featuring a compact platform design and small working footprint, Nano 30 CS supports operators working in ceiling voids, service areas and restricted access environments where larger platforms may not be practical.
Designed for confined space applications, Nano 30 CS can raise an operator to waist height through a ceiling tile opening and can operate within spaces as small as 500 mm x 500 mm when required.
Compact enough to fit through standard doorways, Nano 30 CS combines manoeuvrability, powered elevation and compact access capability for maintenance, installation and servicing applications in restricted environments.
The compact platform design supports elevated access within restricted indoor environments and confined operational areas.
Nano 30 CS can raise an operator to waist height through a ceiling tile opening, supporting maintenance and installation work above suspended ceilings.
The compact design allows operation within spaces as small as 600 mm x 600 mm when required.
Compact dimensions allow Nano 30 CS to pass through standard doorways and operate in confined indoor work environments.
Electric elevation supports controlled positioning and straightforward operation during elevated tasks.
Nano 30 CS is designed for indoor maintenance, servicing and installation applications in operational facilities and restricted environments.
Auto-locking wheels engage during elevation to support positioning for working at height.
The adjustable platform height helps reduce excessive climbing, stretching and awkward working positions during confined space tasks.
Applications & Industries
Nano 30 CS is designed for indoor low-level access applications where operators require compact elevated access within confined spaces and restricted operational environments.
Its compact platform size and manoeuvrability make it suitable for maintenance and installation work above suspended ceilings, within service voids and around restricted infrastructure where larger access equipment may not fit.
Nano 30 CS is commonly used for cable installation, facilities maintenance and inspection work across commercial buildings, operational facilities and public environments.
The platform’s ability to operate within spaces as small as 600 mm x 600 mm supports maintenance tasks in highly restricted access areas where standard low-level access platforms may not be suitable.
Nano 30CS Gallery
How to use the Nano 30CS
Nano 30 CS is designed for straightforward electric operation using intuitive push-button controls. The platform elevates smoothly to the required working height, supporting positioning for confined space elevated work tasks.
Its compact push-around design allows operators to manoeuvre efficiently through restricted indoor environments and confined access points, while the compact platform supports operation around ceiling voids and service infrastructure.
For full operating instructions, safety guidance and maintenance information, refer to the Nano 30CS Operating Manual.
Product
Specifications
Working height 4.95 m
Platform height 2.95 m
Safe working load 200 kg
Platform size 0.53m x 0.55 m
Closed length 1.21 m
Closed width 0.76 m
Closed height 1.94 m
Machine weight 333 kg
Power source 12V DC Electric Motor
Use type Indoor Use
Accessory Options
Tool Tethering System
Designed to help secure tools while working at height, supporting organised working and helping reduce the risk of dropped tools.
